Name: HFHFBBQ26B-MINI-530 Silicon Nitride Igniter
Brand: HEAT FOUNDER Silicon Nitride Igniter, Silicon Nitride Heating Element
SKU: HFHFBBQ26B-MINI-530
Availability: InStock
Rating: 5 (1 reviews)

Item No.: HFHFBBQ26B-MINI-530

【90s Ignition Time & 100% Pit Boss Igniter Replacement】【Patented Aerospace Ignition Technology - Quick To Ignite & Durable, Safe To Use】【Stable Heating & Small Size Igniter】
if you need more technical information,please contact info@heatfounder.com.

Ask for a Solution PDF Format

Description

Advanced Heating Solution for Critical Ignition Applications
Engineered for manufacturers and system integrators, this silicon nitride igniter serves as a critical component in advanced heating devices. Its design targets applications requiring fast, dependable ignition cycles and extended operational lifespan. Ideal clients include OEMs of industrial boilers, pellet stoves, gas burners, and commercial heating appliances seeking to replace an existing hot surface ignitor or optimize the efficiency of their heater element configurations. The igniter’s compact form factor and adaptability facilitate seamless integration within diverse heating assemblies, supporting reliable operation under rigorous industrial demand.

Technical Specifications and Thermal Performance Metrics
Constructed from high-grade Silicon Nitride (Si3N4) ceramic, this ignitor delivers robust thermal stability and mechanical strength across a temperature range of 1100°C to 1300°C. It achieves rapid heat-up times, reaching up to 1000°C within 10 seconds, supported by a high watt density design (120W) that maximizes energy efficiency and longevity—rated for up to 90,000 hours of continuous operation. Compliance with stringent quality certifications including SGS, ISO9001, and Intertek underscores its conformance with international safety and performance standards. Multiple flange options and a 120V power rating enable customization for precise heater element replacement or ignitor replacement needs.

Industry Relevance and Application Versatility
The silicon nitride igniter supports a broad spectrum of industrial heating technologies. Its reliable ignition capability enhances performance in biomass boilers, pellet burner systems, gas stoves, and residential heating appliances that demand consistent hot surface ignitor functionality. This product is also well-suited for fuel cells, medical heating devices, and agricultural combustion systems, where durable heater elements are critical. Its resistant ceramic construction ensures stable ignition under chemical exposure and oxidizing environments, aligning with the rigorous demands of diverse sectors and contributing to cost-effective maintenance cycles through extended operational life.

Product Advantages

Structural Design and System Integration Benefits
The igniter’s structural design incorporates aerospace-level ignition technology combined with Silicon Nitride ceramic’s inherent durability, enabling compactness and high watt density within a minimal footprint. Its modular flange options—ceramic, stainless steel, copper, or customized—allow for streamlined installation and straightforward replacement of water heater element components or hot surface ignitors. This structural versatility facilitates easy incorporation into existing heating systems with minimal disruption to engineering workflows. The igniter’s oxidation resistance and mechanical robustness reduce failure rates and support reliable operation in harsh conditions.

Operational Performance and User-Centric Value
From an operational standpoint, the silicon nitride igniter offers rapid thermal response times and extended service life, reducing downtime and maintenance frequency associated with heater element replacements. The enhanced efficiency in heat generation at 120W power consumption delivers consistent ignition with low energy waste. Certified for quality and safety, the ignitor provides system designers and maintenance teams assurance of performance compliance. This product simplifies part sourcing and serviceability in commercial and industrial heating appliances, optimizing lifecycle costs while maintaining precise ignition control under variable load conditions.

Name	Silicon Nitride Igniter
Model	HFBBQ26B-MINI-530
Material	Silicon Nitride (Si3N4)

Color	black
Voltage	120V
Power	120W
Flange	Ceramic/Stainless Steel/copper/customized
Temp Range	1100~1300 °C/2012~2372℉
Ignition Time	up to 1000°c in 10 seconds
Samples fee	Please contact for confirmation.
Packing	carton
Lead time	5 working days for samples; 12 working days for mass production
QC	Strict quality control under SGS, ISO9001 and Intertek.
Certification	BSCI, ISO9000/1400,BV TUV SGS FSC etc.
Applications
Biomass boiler/burner	Pellet burners
Gas burner/stove	Pellet boiler
Ignition of gas or oil	Pellet burner
Pellet Stove	Pellet BBQ grill
Stove fireplace	Medical-Scientific
Wood pellet stove	Heaters-Agricultural
Particle Burning	Spark Igniters
Fuel cells	EV heating
Gas appliances	Glow plug
Petroleum equipment	Cabin heater
Soldering iron	Gas sensor
gas furnaces,	DPF/Catalyst
gas boiler
Rapid heating: Heating faster. up to 1000°c in 10 seconds Range of temperature:1100~1300 °C/2012~2372℉ Small size / High watt density: High-watt density discharge allow high thermak efficiency. Long working life:10 years possible,90,000 hours High insulation Direct water and kerosene heating Vacuum environment Oxidation and chemical resistance Output switching Temperature sensing

Use Scenarios

Biomass Boiler Systems Ignition Integration
In biomass boiler environments, reliable ignition is fundamental to efficient fuel combustion and emissions control. The silicon nitride igniter functions as a durable heater element designed to initiate combustion rapidly and reliably, even in fluctuating operating conditions typical of biomass fuel variability. Its advanced ceramic composition withstands corrosive flue gases and high thermal cycling, ensuring consistent performance and reduced replacement intervals compared to traditional elements. Integration with burner control systems is facilitated by the ignitor’s quick heat-up profile and compliance with international standards, meeting stringent energy efficiency and emission criteria required in industrial biomass applications.

Pellet Stove and Commercial Gas Burner Replacement
This ignitor is specifically engineered for seamless replacement tasks in pellet stoves and commercial gas burners requiring robust hot surface ignitor components. It addresses the operational necessity for fast, consistent ignition to optimize appliance start-up times and maintain stable flame currents. The silicon nitride igniter’s compact size and multiple flange configurations enable retrofitting into existing appliance assemblies without redesign. Its resistance to oxidation and thermal shock extends service intervals and improves reliability in commercial heating environments, thus enhancing system uptime and reducing service costs by simplifying ignitor replacement processes.

FAQ

What materials are used in the Silicon Nitride Igniter?
Our Silicon Nitride Igniter is made from high-grade Silicon Nitride (Si3N4) ceramic, known for superior thermal stability and mechanical strength at high temperatures. This ensures durable performance and resistance to oxidation and chemical exposure in various heating applications.

Can the Silicon Nitride Igniter be customized to fit specific equipment?
Yes, we provide customization options including flange materials such as ceramic, stainless steel, copper, or fully tailored designs. We work closely with you to ensure the ignitor replacement fits your application’s exact technical requirements.

How quickly can I receive samples of the Silicon Nitride Igniter?
We ship samples within approximately 5 working days to facilitate your evaluation. For bulk orders or replacing water heater element needs, lead time is about 12 working days, ensuring timely delivery aligned with your project schedule.

Is the Silicon Nitride Igniter suitable for replacing a water heater element in industrial settings?
Absolutely. Our igniter’s high watt density and rapid heating make it ideal as a heater element replacement in various industrial water heaters or heating appliances, offering a long service life of up to 90,000 hours for reliable operation.
